SCARA kit compatible with KUKA KR 6 R700 Z200

SCARA kit compatible with KUKA KR 6 R700 Z200

Protection kit for SCARA robot designed to provide optimum protection for the robot in harsh environments or to prevent contamination of a controlled area.

View full details

Characteristics

  • Complete, waterproof protection of the robot screw
  • Easy installation and maintenance
  • Resists temperatures from -40°C to 80°C
  • Robust design resistant to oils, solvents, dust, high-pressure cleaning and UVs
  • Eclore bellows resistant to 10 million cycles

Specifications

Hd Extended height 610 mm
Hc Compressed height 496 mm
L Kit length 170 mm
l Kit width 90 mm
Max stroke Maximum stroke 114 mm
Standard stroke Stroke without kit 200 mm
H Upper axis position 86 mm
